Laydown Concrete Kibble 2.0 cum - Clamshell Gate and Funnel with Lay Flat Hose

This Concrete Kibble is a heavy duty, roll-over style for easy transfer of concrete on site by overhead crane. Suits large applications with models available for up to 3cu.m capacity. Roll-over (laydown) style allows filling from concrete dispensing chute.
Part No: EW-LCK20-CGF
*
$7,830.00 excl GST

Laydown Concrete Kibble 2.0 cum - Clamshell Gate and Funnel with Lay Flat Hose


This Concrete Kibble is a heavy duty, roll-over style for easy transfer of concrete on site by overhead crane.

Features:

  • Suits large applications with models available for up to 3cu.m capacity
  • Roll-over (laydown) style allows filling from concrete dispensing chute
  • Fitted with a lever operated 400mm x 400mm clamshell gate
  • Removable concrete funnel with 2m lay-flat hose allows controlled flow when filling wall cavities, columns or narrow formwork
  • Fork pockets fitted for transport around the work site
  • Hydraulic Kibble Option available to remotely control kibble
  • Enamel paint finish

Specifications:

  • Volume Capacity (cu.m) : 2.0
  • Working Load Limit (kg) : 5000
  • Filling Height (mm) : 1380
  • Laydown Dimensions (mm) : 2965 x 2010 x 2000
  • Pocket Size (mm) : 185 x 85
  • Pocket Centres (mm) : 750
  • Unit Weight (kg) : 900
  • Lay Flat Hose Dimensions (mm) : 200 diameter x 2000
